it is a new type of high-energy chemical power composed of negative multi-component aluminum alloy, positive air electrode and food grade alkaline aqueous solution as the electrolyte.

Equipped with 11 alloy plates, the rate power is 200w,so far this model come out 2 kinds of aluminum plate,one thickness is 3mm ,another is 5mm,their capacity accordingly can up to 2000wh(3mm)/3500wh(5mm),the device can generate electricity by adding electrolyte powder and water and does not need to be connected to external commercial power for recharging. The consumed alloy plates can be replaced by new ones for continuous use.

which are ideal and portable (emergency) power suppliers for in and around your home or outside during outdoor activities, so that you can continue to use your electrical appliances at any time. They’re similar to power banks but have a larger capacity, higher output power 200w, Equipped with AC outlet, DC carport and USB charging ports, they can keep all your gear charged, from smartphones,laptops, to CPAP and appliances....
Availability:



Adding water to generate electricity in 10 seconds! Self-generating electricity power source.

New energy --- ALuminum air battery  Generator,
Intelligent Aluminum Air Electrolytes Battery , is a new type of high-energy chemical power composed of negative multi-component aluminum alloy, positive air electrode and food grade alkaline aqueous solution as the electrolyte.

Equipped with 11 alloy plates, the rate power is 200w,so far this model come out 2 kinds of aluminum plate,one thickness is 3mm ,another is 5mm,their capacity accordingly can up to 2000wh(3mm)/3500wh(5mm),the device can generate electricity by adding electrolyte powder and water and does not need to be connected to external commercial power for recharging. The consumed alloy plates can be replaced by new ones for continuous use.

which are ideal and portable (emergency) power suppliers for in and around your home or outside during outdoor activities, so that you can continue to use your electrical appliances at any time. They’re similar to power banks but have a larger capacity, higher output power 200w, Equipped with AC outlet, DC carport and USB charging ports, they can keep all your gear charged, from smartphones,laptops, to CPAP and appliances....

All substances of this device are environmentally friendly and non-toxic and non-flammable ,non-explosive.it contribute to the sustainable development of the environment.
Specification
Model
Al-AC 220V200W
Size
400*245*290mm
Dry Net Weight(machine without electrolyte solution)
10.8kg
electrolyte powder
1000g/bag
Aluminum plate for 2000wh
180*168*3mm/187g/pc
Aluminum plate for 3500wh
180*168*5mm/270g/pc


Rated Power
200W
Capaticy
2000wh(with 3mm aluminum plate)/3500wh(with 5mm aluminum plate)
Peak power
270W
Output function
LED Lighting,USB:DC5V/3A max,Type-c:60w max,car cigarette lighter:DC12V/10A max,AC:220W/200W,Pure sine wave
Smart protection
protection for over voltage/low voltage/over load/over temperature
Charge Mode
Mechanical charging, changing negative alloy plates and electrolyte
Battery System
Alkaline Electrolyte
Principal material for positive electrode
Waterproof layer, collecting layer and Oxygen reduction catalysis layer
Principal material for negative electrode
Aluminum Alloy


Operating Temperature Range
10℃-50℃
Environment Protection
Environmentally friendly, no pollution, no heavy metal, no toxicity and no harm
Security
Nonexplosive and nonflammable
Applications
Outdoor, camp, home application ,emergency rescue,communication
Warranty
1 Year








9306d3f8ba3d6c38c182dd2c491d57d




Patents and Certifications

4 Invention Patents

13 Utility Model Patents

PCT International Patent Grant

Design patent

Certifications: CE EMC / FCC / SDOC / CE LVD/ ROHS / MSDS certification
